User's Manual
274
●
Make sure that the Device is connected with alarm input device.
●
The Device supports 16-channel alarm input. Configure according to actual port of alarm input
device. Take ALARM1 port connection for example.
Step 1 Click , or click on the configuration page, and then select EVENT.
Step 2 Select the root node in the device tree on the left.
Step 3 Select Device Alarm > IO1.
Figure 8-60 IO1
Step 4 Click to enable local alarm.
Step 5 Set parameters.
Table 8-21 Local alarm parameters description
Name In the Alarm name box, enter a name for the alarm.
Type Select alarm input device type. Both NO and NC are supported.
Debouncing The system records only one event during this period.
Step 6 Click Deployment Time to select schedule from the drop-down list.
After setting deployment period, system triggers corresponding operations when there is
a motion detection alarm in the specified period.
●
Click
View Schedule to view detailed schedule settings.
●
If the schedule is not added or the added schedule does not meet actual needs, click
Add Schedule. See "8.8.4 Schedule" for detailed information.
Step 7 Click
Actions to set alarm actions. See "8.4.1 Alarm Actions" for detailed information.
Step 8 Click Save.
8.4.3 Remote Device
Set alarm actions of remote device, including video detection alarm, offline alarm and AI plan of
remote device.
