Click to set the whole image as the detection area.
Figure 6-66 In Area No.
Step 5 Set parameters.
Table 6-13 Parameter description of In Area No.
Area People
Counting Alarm
1. Click to enable the alarm.
2. Set people number threshold.
●
If you select and then enter a number, alarm is triggered
when the detected number is larger or equal to the number that
you entered.
●
If you select and then enter a number, alarm is triggered
when the detected number is smaller or equal to the number that
you entered.
Strand Alarm
1. Click to enable the alarm.
2. Set time threshold for the alarm. When the dwell time of any person
in the area is greater than the threshold, an alarm will be triggered.
Max Detect Height 0–300.
Min Detect Height 0–300.
Step 6 Select a schedule in the Deployment Time drop-down list.
Alarms are triggered only within the scheduled time.
Step 7 Click
Actions to set alarm linkage actions.
Step 8 Click Save.
6.4.4 Configuring Queuing Detection
The system counts the number of people queuing in the detection area. When the number of people
exceeds the threshold or the queue time is longer than the pre-defined time, an alarm is triggered.
Step 1 Click , click , and then select
EVENT.
Step 2 Select a camera in the device tree, and then select AI Application > People Counting >
