User's Manual
269
Figure 8-53 Face
Step 4 Configure display filter information.
After setting filter criteria, only the qualified detection result will be displayed. For
example, enable Age, and then select youth from the drop-down list. The tracking box and
the features panel only display the human face of the youth age.
1) Click to enable corresponding filter type.
2) Set display filter criteria. Click to set the filter color.
Step 5 Click in the right of
Show Tracking Box to enable.
After enabled, when the system detects face or human, tracking box will be shown beside
the face or human in the view window.
Figure 8-54 Tracking box
Step 6 Click in the right of Features Panel to enable, and select the features to be displayed
on the LIVE page.
After enabled, there is a features panel on the right side of the view window.
