Working mode
Set RAID resources allocation mode. The default setup is self-adaptive.
●
Self-adaptive means the system can automatically adjust RAID
synchronization speed according to current business load. When
there is no external business, the synchronization speed is at high
speed. When there is external business, the synchronization speed
is at low speed.
●
Sync first: Allocate resources to RAID synchronization first.
●
Business first: Allocate resources to business first.
●
Load-Balance: Allocate resources to business and RAID
synchronization equally.
Name Set RAID name.
●
Auto: System creates RAID5 according to the HDD amount.
1) Select Auto.
Figure 8-69 Create RAID (2)
2) Set parameters.
Table 8-27 Auto parameters description
Storage Device Select storage device of the HDD.
