User's Manual
303
Figure 8-94 IP Filter
Step 2 Select IP access rights.
●
Allow all access: It is to allow all IP addresses in the same IP segment to access the
device.
●
Reject access list: It means the IP address in the list cannot access the device.
●
Allow access list: It means the IP address in the list can access the device.
Step 3 Add IP host.
The following steps are to set reject access list or allow access list.
1) Click Add.
2) Select
Add Type, and set IP address or MAC address of IP host.
●
Single IP: Enter host IP address.
●
IP segment: Enter IP segment. It can add multiple IP addresses in current IP
segment.
●
MAC: Enter MAC address of IP host.
3) Click
OK to add the IP host.
System displays added IP host list.
●
Click
Add to add more IP hosts.
●
Click to edit the IP host.
●
Select an IP host and then click
Delete to delete.
Step 4 Click
Save.
