User's Manual
39
Device has 4 Ethernet ports by default. Make sure that at least one Ethernet port has been connected
to the network before you set IP address.
Step 1 On the completion page of initialization, click
Enter Quick Setting.
Figure 5-4 IP setting
Step 2 Configure IP address.
1) Click of the corresponding NIC.
Figure 5-5 Edit Ethernet network
2) Set parameters.
Table 5-4 TCP/IP parameters description
Speed Current NIC max network transmission speed.
