User Manual UMN:CLI
V8102
829
the following command.
Connects VoIP profile to the current VoIP service.
NAME: VoIP profile name
Disconnects the specified VoIP profile.
You need to create a VoIP profile first to connect the existing VoIP profile to the current
VoIP service. For the details of how to create and configure the VoIP profile, see 13.7
VoIP Profile.
13.4.6.3 IP-path Managed VoIP
If you configure the VoIP service management mode as IP-path managed by using voip-
profile ip-path command, you need to set IP-path configuration in VoIP IP-path Configu-
ration mode.
When you use the voip-profile ip-path command, you enter automatically VoIP IP-path
Configuration mode.
Whenever an ONU is deployed with the IP-path managed VoIP service, the OLT should
assign the URL of a VoIP configuration file to communicate with the ONU VoIP client. The
V8102 provides an authentication method for ONUs to have access to the VoIP configu-
ration server.
To configure IP-path managed VoIP mode, use the following command.
Configures a VoIP configuration server.
URI: IP-path URI
ip-path auth NAME [PASSWD]
Sets the user ID and password for IP-path managed
model to have access to VoIP configuration server.
NAME: user name used for authentication
PASSWD: password used for authentication
no ip-path { uri | auth }
Deletes the configured VoIP configuration server or
authentication information.
To specify the protocol on the current VoIP service, use the following command.
protocol { h248 | sip | mgcp}
Specifies the protocol on the current VoIP service.
sip: Session Initiation Protocol
h248, mgcp: Media Gateway Control protocol
(= MEGACO)
13.4.6.4 POTS UNI Configuration
To configure the user network interface, use the following command.
