UMN:CLI User Manual
V8102
830
Command
Mode
Description
uni {pots | isdn} POTS_NUMBER
Traffic-VoIP
Configures the VoIP user network interface.
pots: POTS (Plain Old Telephone Service)
isdn: ISDN (Integrated Services Digital Network) (future
release)
POTS_NUMBER: POTS port number
no uni {pots | isdn}
POTS_NUMBER
Deletes the configuration of UNI.
If you specify UNI as the POTS by using uni pots command, you need to perform the
configuration for the interface in VoIP-UNI Configuration mode as follows:
When you use the uni pots command, you enter automatically VoIP-UNI Configuration
mode, where you can configure the specified POTS interface.
To specify the impedance for the POTS UNI, use the following command.
Command
Mode
Description
impedance {600 | 900 | 750 | 820 |
1050}
Traffic
VoIP-UNI
Specifies the impedance for the specified POTS UNI.
600: 600 Ohm (default)
900: 900 Ohm
750: C1=150 nF, R1=750 Ohm, R2=270 Ohm
820: C1=115 nF, R1=820 Ohm, R2=220 Ohm
1050: C1=230 nF, R1=1050 Ohm, R2=320 Ohm
no impedance
Deletes the configured impedance for the POTS UNI.
To specify the on-hook transmission type, use the following command.
Command
Mode
Description
transmission-path {full-time |
part-time}
Traffic
VoIP-UNI
Allows setting the POTS UNI either to full-time on-hook
transmission or part-time on-hook transmission.
(default: full-time)
no transmission-path
Deletes the configured on-hook transmission type.
To specify Rx/Tx gain value for the receive/transmit signal, use the following command.
Command
Mode
Description
gain rx VALUE tx VALUE
Traffic
VoIP-UNI
Specifies Rx/Tx gain value for the receive/transmit
signal.
VALUE: –120 (–12.0 dB) to 60 (+6.0 dB) (form: two's
complement number, default: 0)
