Chapter 5 Errors and Troubleshooting
202
AS-410M Auto Slide Preparation System
5-3-4 Slide Transfer Unit errors
Error
code
On-screen message Possible cause Solution
4001
<Error Message>
Unit: Slide Transfer Unit
Part: Slide feeder
Symptom: Overrun
An overrun error occurred in the
slide feeding motor.
•Remove slide cassette and slide
glasses.
•Confirm no slides stuck together.
•Press the HOME POSITION button
to initialize.
4002
<Error Message>
Unit: Slide Transfer Unit
Part: Slide transfer
Symptom: Overrun
An overrun error occurred in the
slide transfer motor.
•Remove slide glasses and obstacles
on the on the slide transfer area.
•Press the HOME POSITION button
to initialize.
4003
<Error Message>
Unit: Slide Transfer Unit
Part: Mounting
Symptom: Overrun
An overrun error occurred in the
mounting motor.
•Remove slide glasses and obstacles
in the mounting area.
•Press the HOME POSITION button
to initialize.
4004
<Error Message>
Unit: Slide Transfer Unit
Part: Slide feeder
Symptom: Limit
A limit error occurred in the slide
feeding motor.
•Remove slide cassette and slide
glasses.
•Confirm no slides stuck together.
•Press the HOME POSITION button
to initialize.
4005
<Error Message>
Unit: Slide Transfer Unit
Part: Slide transfer
Symptom: Limit
A limit error occurred in the slide
transfer motor.
•Remove slide glasses and obstacles
on the on the slide transfer area.
•Press the HOME POSITION button
to initialize.
4006
<Error Message>
Unit: Slide Transfer Unit
Part: Mounting
Symptom: Limit
A limit error occurred in the
mounting motor.
•Remove slide glasses and obstacles
in the mounting area.
•Press the HOME POSITION button
to initialize.
4007
<Error Message>
Unit: Slide Transfer Unit
Part: Slide feeder
Symptom: Initialization error
The slide feeding motor failed to
complete returning to the home
position within 60 seconds.
•Remove slide cassette and slide
glasses.
•Confirm no slides stuck together.
•Press the HOME POSITION button
to initialize.
4008
<Error Message>
Unit: Slide Transfer Unit
Part: Slide transfer
Symptom: Initialization error
The slide transfer motor failed to
complete returning to the home
position within 60 seconds.
•Remove slide glasses and obstacles
on the on the slide transfer area.
•Press the HOME POSITION button
to initialize.
4009
<Error Message>
Unit: Slide Transfer Unit
Part: Mounting
Symptom: Initialization error
The mounting motor failed to
complete returning to the home
position within 60 seconds.
•Remove slide glasses and obstacles
in the mounting area.
•Press the HOME POSITION button
to initialize.
4010
<Error Message>
Unit: Slide Transfer Unit
Part: Left pinch roller
Symptom: Operation error
The left pinch roller air cylinder
failed to complete its motion within
5 seconds; or the two position
detection sensors made ON
simultaneously.
•Check that the pressure of the
compressor is within the specified
range.
•Check the left pinch roller drive for
obstacles and remove if any by an
air duster.
•Press the HOME POSITION button
to initialize.
4011
<Error Message>
Unit: Slide Transfer Unit
Part: Right pinch roller
Symptom: Operation error
The right pinch roller air cylinder
failed to complete its motion within
5 seconds; or the two position
detection sensors made ON
simultaneously.
•Check that the pressure of the
compressor is within the specified
range.
•Check the left pinch roller drive for
obstacles and remove if any by an
air duster.
•Press the HOME POSITION button
to initialize.
4012
<Error Message>
Unit: Slide Transfer Unit
Part: Slide UP/DOWN
Symptom: Operation error
Slide UP/DOWN air cylinder f
failed to complete its motion within
5 seconds; or the two position
detection sensors made ON
simultaneously.
4013
<Error Message>
Unit: Slide Transfer Unit
Part: Transfer Arm UP/DOWN
Symptom: Operation Error
The slide transfer arm UP/DOWN
air cylinder failed to complete its
motion within 5 seconds; or the
two position detection sensors
made ON simultaneously.
To Next Page
