C
ha
pt
er
2
-
In
st
al
la
ti
on
-
AS
-4
10
M
A
ut
o
Sl
id
e
P
re
p
ar
at
io
n
S
ys
te
m
39
System2:
Main Unit with 400-slide dry chamber unit option
Required installation space = 2,450
mm
W
×
1,600
mm
D
×
2,030 mm H
* In this configuration, the System weighs approx. 900 kg.
* Ensure that the System’s center of gravity in
the depth direction will be
positioned near the center of
the installation space.
Center of
gravity
４５０ｍｍ
５０ｍｍ
２,４５０ｍｍ
１,６００ｍｍ
２,０３０ｍｍ
４５０ｍｍ
４５０ｍｍ
４５０ｍｍ
