DNS AS-410M User Manual

Chapter 3 -Preoperational Setup-
64
AS-410M Auto Slide Preparation System
< System with 400-slide dry chamber option unit (DU-400) >
The 400-slide dry chamber option unit can accommodate up to four slide collection boxes.
The 400-slide dry chamber consists of two shelves for drawers, each of which can accommodate
two slide collection boxes.
Slide collection boxes are loaded first into the upper front shelf, followed by the upper back
shelf, the lower front shelf, and the lower back shelf (Box 1 → Box 2 → Box 3 → Box 4 shown
below).
Each slide collection box bears a FRONT label and a number label (①, ②, ③, or ④) on
the top. Install each slide collection box ① (upper front shelf), ② (upper back shelf) ③ (lower
front shelf), and ④ (lower back shelf), so that their FRONT labels will come to the front side.
１
２
FRONT label
Number label
３
４
