D-6 Infinity Vista VF6
D TECHNICAL DATA
SpO
2
Pod (Masimo SET)
Size (H x W x D) 39 x 58 x 135 mm (1.5 x 2.3 x 5.3 in.)
Weight 0.15 kg (0.33 lbs.)
Connections PodCom: for power and connection to monitor
Cable Connection: for sensor cable
Power Source Powered directly from monitor
Protection Against Electric Shock IEC 68-2-27: Minimum of 50 G, 11 ms, half sine
Vibration Sinusoidal IEC 68-2-6: 0.040 double amplitude displacement
(5-32 Hz), 2 G peak (32-500 Hz)
Random Vibration IEC 68-2-34: 20-500 Hz, ASD = 0.02G2/
Hz, Low reproducibility, 9 minutes
Mode of Operation Continuous
Environmental
Requirements
Temperature:
(operating:) 5 to 45qC (41 to 113qF)
(storage:) -20 to 60qC (-4 to 140qF)
Relative Humidity:
(operating:) 10 to 95%, non-condensing
(storage:) 10 to 95%, (with packaging)
Atmospheric Pressure:
(operating:) 485 to 795 mmHg (64.7 to 106 kPa)
(storage:) 375 to 795 mmHg (50 to 106 kPa)
