Finding a place for the product
When relocating the product, always choose a location that has
adequate space for easy operation and maintenance. Use the
following illustration as a guide for the amount of space required
around the product to ensure smooth operation. Dimensions
shown in the illustration below are in millimeters.
a. 920 mm (36.2 in.)
b. 258 mm (10.2 in.)
c. 868 mm (34.2 in.)
d. 100 mm (3.9 in.)
e. 300 mm (11.8 in.)
a
e
d
b
c
