Console Overview 13
Littlites®
Outputting DMX
Power Button
The power button on the front of the console is used to power up or power down. A separate
hard power switch, located on the rear panel, can be used to disconnect power from the
console’s internal components.
CAUTION: It is recommended that you safely power down the console through the
software, Displays>Power Off Device, before disconnecting power from the console.
WARNING: Before servicing your console, you must switch off the power on the rear
panel and disconnect the power cord completely.
USB Ports
One USB port is provided on the front of the console to connect any USB storage device.
Additional USB ports on the rear panel of the console connect peripherals such as an
alphanumeric keyboard, pointing device, or touchscreen control for external monitors.
CAUTION: The USB ports cannot be used for charging devices such as cell phones.
External Monitors
Element can support up to 2 display port, DVI-I, or DVI-D monitors. Display port can use an
active adapter to VGA, DVI, or HDMI. DVI-I can be converted to VGA with a passive adapter.
Note: While it is possible to assign a resolution lower than the minimum
(1280x1024), it is recommended to be at 1280x1024 or higher.
For monitor configuration, please see
Monitor Arrangement (on page409)
.
Control Keypad
The control keypad area is divided into several sections including record targets, numeric
keypad with modifiers, display, softkeys, navigation, and special function controls.
Display and navigation keys are used for quick access to common displays, format, paging, and
navigation within displays.
