Recorded load
•
Actual load
{Dimmer Feedback} displays the following information, which can be modified from Element by
clicking on the value and entering in a new value:
•
Firing Mode
•
Control Mode
•
Curve
•
Threshold
•
Scale Minimum
•
Scale Maximum
•
Preheat Enable
•
Preheat Timing
•
Advanced Features (AF) Enable
Element support the following softkey commands from this display:
•
{Ignore Errors}
•
{Clear Errors}
Note: Clearing CEM+ or CEM3 errors from Element will be temporary unless the
errors have been fixed at the CEM+ or CEM3. Errors displayed on Element will clear on
their own once they have been cleared from the CEM+ or CEM3. Some CEM+ or CEM3
errors can only be cleared at the CEM+ or CEM3.
{Device Details} - appears when the current address is patched to a RDM device. RDM devices
must be enabled through the ECU and discovered through the patch. See RDM (on page416) ,
{Patch} Display and Settings (on page104) , and Errors and Warnings (on page114) .
{Device Details} displays the information that it receives from the device and allows some
changes to be made to:
Note: Changes may take a few seconds to make. They will propagate to the RDM
device and then back to the console’s patch and about displays.
•
Device Label (displayed at the top by the address number)
•
DMX Address (can be changed in this display by clicking on the property or value)
Note: Changing the address can not cause any part of the fixture to move to a
different universe or communication with the device may be lost. The universe is set
into the gateways port configuration.
Note: Details displayed will vary based on the device.
•
DMX Label (same as the device label, but the label can be changed here by clicking on
the property or value)
•
Type
•
Manufacturer
•
Device ID
•
Footprint
•
Version
•
Lamp State
•
Lamp Hours
