System Basics 65
Master Only
Master Only is a fader option that can be assigned in the fader configuration display (Tab 36) or
in the fader list (Tab 35) for submasters, presets, and palette faders. Submasters can also be
configured in the Submaster List (Tab 15).
Master Only faders are used to set a level for content to fade to. The slider can be used to live
adjust levels when the fader has been activated via the bump button.
Master Only faders default to Full.
To set the fader level from the command line, use [Fader] [n] [At] [level] [Enter].
Note: If content is set to proportional, Master Only fades all content to the setting of
the fader when bumped. If set to I-Master, the fader masters the intensity, but non-
intensity goes to the end state in time when the content is triggered.
Channel and Parameter Filters on Faders
Channel and Parameter Filters can be used to allow only specified data to be played back.
These are playback filters, and do not impact how data is recorded.
Channel and Parameter Filters can be associated with the following targets for playback:
Cue lists
Submasters
Presets
Palettes
Note: Channel and Parameters filters can also be used with Global Effects Faders.
See Global Effects Fader (on page301)
Note: For presets and palettes, channel and parameter filters can only be assigned in
the fader configuration display (Tab 36) or in the fader list (Tab 35).
For cue lists and submasters, channel and parameter filters can be set in the following areas:
Cue List Index
Submaster List
Fader configuration display (Tab 36)
Fader list (Tab 35)
In Live using the {Properties} softkey
Tap or click on {Chan Filter} to assign channels or groups. Tap or click on {Param Filter} to open
a list of available parameters that you can filter.
Note: Filters will travel with their assigned cue lists and submasters wherever they are
mapped.
When a filter has been applied, an indicator will display in the fader ribbon. C will display for
channel filter, and F is for parameter filter.
