92
CMS-D3 Central Management Software
1 DVR/Camera List: Shows a list of all DVRs/camera groups and cameras connected to the
client software.
• Camera groups are shown with an
icon. DVRs are shown with an icon. Double click
a DVR or camera group expand the DVRs or cameras in it.
• Cameras are shown with one of the following icons:
Camera online, but not selected in live view.
Camera online and selected in live view.
Camera is offline (connection issue).
• Click-and-drag cameras, DVRs, or camera groups to the display grid to open them.
TIP: You can click-and-drag cameras from different DVRs to create custom views.
2 Hide DVR/Camera List: Click the arrow to hide/show the DVR/Camera List.
3 Alarm:
Click to sho
w the Alarm Panel. The Alarm Panel shows a list of system alarms and
events, such as motion detection events.
4 Clear Alarms : Click to clear all alarms from the list.
5 Mute Alarm Sound
: Click to mute/un-mute the audio alarms that are played when events
occur. To configure the alarm sounds that are played, see “Alarm Sound” on page 111.
6 Main View T
oolbar:
• Full-Screen : Click to open the display grid in full-screen. Press ESC to exit full-screen.
• Select Layout
: Click to select a display grid layout.
• Stop Live Display
: Click to stop camera streaming on all channels.
• Screenshot
: Click to save a screenshot of the currently selected channel.
• Manual Recor
d : Click to start/stop manually recording the currently selected channel.
• Previous/Next
: Click to go to the previous or next camera or page.
• Sequence
: Click to configure Sequence mode.
• Volume
: Click to control volume.
