FLIR D3200 Series User Manual

37
Using the Main Menu
To adjust the transparency of
on-screen menus:
1 Click the Output t
ab.
2 Drag the Transparency slider t
o adjust
transparency.
3 Click Apply
to save your settings.
Adjusting the Video Margin
If you connect your DVR to a BNC
monitor, you can adjust the video
margins.
NOTE: You must select the BNC output
mode t
o adjust the margins. Press 0
three times on the remote control to
switch the output mode between
BNC mode and VGA/HDMI mode.
When BNC mode is selected, the
mouse cursor appears on the BNC
monitor.
To adjust the video margin:
1 Click the Output tab.
2 Click the
Margin button.
3 Drag the sliders to the left or right to
adjus
t the Left, Right, Top, or Bottom
Margin.
4 Click Apply to save your settings and click
OK to confirm.
Adding Privacy Zones
A privacy zone allows you to block out
up to 4 portions of each channel with a
black square.
ATTENTION: Areas covered by privacy
zones are not visible in recordings.
To configure a privacy zone:
1 Click the Privacy Zone tab.
2 In the
Channel drop-down menu, select
the channel you wish to configure.
Privacy Zone
3 Configure the following:
• Channel: Select the channel y
ou wish to
configure.
• Privacy Zone: Select ON to enable privacy
zones or
OFF to disable privacy zones.
• Area Setup: Select the Ar
ea1~4
checkboxes to enable up to 4 privacy
zones.
4 Click the Setup button ne
xt to Mask Area.
The Privacy Area setup screen opens.
Click and drag to move privacy zones
Click Inside the edge and drag to resize
• Click on a privacy area and drag to change
its location.
