9
Basic Setup
Step 4: Connect the Monitor
• Connect an HDMI cable (not included) from the HDMI port to the TV or monitor (recommended)
OR;
• Connect a VGA cable (not included) from the VGA port to the monit
or.
HDMI
VGA
8-channel model shown
Step 5: Connect the Power Adapter and Power on the DVR
• Connect the included power adapter to the DC 12V port. Connect the end of the power adapter
to a wall socket or a surge protector.
• Turn the power switch to I to turn on the D
VR. At startup, the system performs a basic system
check and runs an initial loading sequence. After a few moments, the system loads a live
display view.
8-channel model shown
DC 12V port
ON
Default System Password & Port Numbers
By default, the system user name is admin and the password is
000000. Passwords are enabled by default and are required to
access the Menu Bar or Main Menu. It is essential that you create
your own password. For details, see “Managing Passwords” on
page 31.
• The system requires a user name and password to log in to the system remotely using a
computer or mobile device.
• ALL the syst
em port numbers below must be port forwarded on your router to log in to your
system over the Internet or an internal network (LAN).
