15
Using the On-Screen Display
Using the Menu Bar
The Menu Bar allows you to access the Main Menu and control basic functions of the DVR.
To access the Menu Bar:
1 Right-click or mov
e the mouse cursor to the bottom of the screen to access the Menu Bar.
Main Menu
Split screen
PTZ
Start / Stop
PTZ Cruise
Search Menu
Start/Stop
Recording
Sequence
Volume
Zoom
PIP1X1
Lock
PIP1X2
Menu Bar Icons
• Main Menu: Opens the Main Menu.
• Lock: Click to l
ock the Main Menu unless the password is entered. Lock icon is not visible
unless passwords are enabled.
• Split Screen buttons: Sel
ect split-screen layout.
• PTZ: Opens the PTZ contr
ols.
• Start / Stop PTZ Cruise: Start or s
top the PTZ cruise function.
• Zoom: Opens digital zoom. Mus
t be in Full-screen / Live Viewing Mode.
• Record Search: Opens the DVR Search Menu. This allows you to search for video recorded
on the D
VR.
• Start / Stop Recording: Start or s
top DVR recording on all channels. Password required; does
not override scheduled recording.
• Start / Stop SEQ: Start or s
top Sequence Mode. In Sequence Mode, DVR automatically switches
between channels every few seconds.
• PIP 1X1: Enable Pictur
e in Picture Mode with 1 camera in full screen and 1 in a small window.
• PIP 1X2: Enable Pictur
e in Picture Mode with 1 camera in full screen and 2 in small windows.
• Volume: Adjust the DVR volume (audio-capable cameras required, not included).
