Appendix A: System Specifications
Appendix A: System Specifications
Operating System Embedded LINUX
Pentaplex Simultaneous View, Record, Playback, Backup &
Remote Monitoring
Number of Channels 4/8/16/32 Channel
System Navigation USB Mouse, IR Remote Controller
User Authority By user group
System
Inputs/Outputs
Video IN D3304: 4 x 1Vp-p, CVBS, 75ohms, BNC
D3308: 8 x 1Vp-p, CVBS, 75ohms, BNC
D3216: 16 x 1Vp-p, CVBS, 75ohms, BNC
D3316: 16 x 1Vp-p, CVBS, 75ohms, BNC
D3332: 32 x 1Vp-p, CVBS, 75ohms, BNC
Video Outputs 1 x HDMI, 1 x VGA, 1 x BNC (D3304 / D3308 / D3216) / 2 x BNC
(D3316 / D3332)
Loop Output D3304: 4CH, D3308: 8CH, D3216: 16CH, D3316: 16CH,
D3332: 16CH
Audio IN D3304: 4CH BNC, D3308: 8CH BNC, D3216: 4CH BNC,
D3316: 16CH BNC, D3332: 16CH BNC
Audio OUT D3304: 1CH BNC, D3308: 1CH BNC, D3216: 1CH BNC,
D3316: 2CH BNC, D3332: 2BNC
USB Port 2x USB, USB 2.0
Alarm IN D3304: 4CH, D3308: 8CH, D3216: 8CH, D3316: 16CH
D3332: 16CH
Alarm OUT D3304 / D3308 / D3216 / D3316: 1CH, D3332: 4CH
PTZ Control RS-485 Pelco D & P Protocol
Display
Video Output Resolution 800*600,1024*768, 1280*1024,1440*900, 1920x1080
Live Display D3304: 1, 4
D3308: 1, 4, 9
D3216/D3316: 1, 4, 9, 16
D3332: 1, 4, 9, 16, 25, 32
Recording
Video Compression H.264
Audio Compression G.711
Recording Resolutions Supported NTSC: 960x480 (960H), 960x240, 720x480 (D1), 720x240
(2CIF), 480x240, 360x240 (CIF)
PAL: 960x576 (960H), 960x288, 720x576 (D1), 720x288 (2CIF),
480x288, 360x288 (CIF)

FLIR D3200 Series Specifications

General

Brand	FLIR
Model	D3200 Series
Category	DVR
Language	English
