6
Rear Panel
D3216 (16-Channel)
1 2 3 4 5 6 7
119 12 13 14 158 10
1 eSATA: Connect a self-powered eSATA external hard drive (not included) for data backup.
2 Audio Input: BNC inputs for audio-enabled cameras (not included) or self-powered
microphones (not included).
3 Video Input: Connect BNC camer
as.
4 Video Output: BNC output for e
xternal monitor.
5 VGA: Connect a VG
A monitor (not included) to view the system interface.
6 PTZ / Alarm Block
: Connect compatible PTZ cameras (not included) or alarm devices (not
included).
7 IR-EXT: Service onl
y; not supported.
8 Loop Out 5~16: Connect Octopus c
able to connect channels 5~16 to a Loop Out monitor.
9 Loop Out 1~4: BNC outputs to c
onnect channels 1~4 to a Loop Out monitor.
10 Audio Out: BNC output for 1 audio channel (e.g. speak
ers).
11 HDMI: Connect to a HDMI-c
ompatible TV or monitor (not included) to view the system
interface.
12 LAN: Connect a CA
T 5 RJ45 Ethernet cable for local and remote connectivity.
13 USB Port: Connect a USB mouse (included) or USB flash drive (not included) for data backup
or firmwar
e updates.
14 DC12V: Connect the included AC po
wer adapter.
15 On / Off Switch: Turns the D
VR on or off.
