145
Appendix A: System Specifications
Playback
Playback Channel 1/4/8/16 Adjustable
Playback Speed Variable Max 16x
Playback Players Backup Player
Search By time & event
Log Search Up to 1,000,000 lines for motion detected, configuration
changes, c
onnects/disc
onnects and video loss.
Audio Play Yes
Storage D3304/D3308/D3216/D3316: Up to 2HDDs (SATA), 2.5" or 3.5"
D3332: Up to 8HDD (SATA), 3.5"
Maximum Capacity D3304/D3308/D3216: Up to 2x2TB
D3316: Up to 2x3TB
D3332: Up to 8x3TB
Backup Media USB Flash Drive, USB External HDD, E-SATA, External HDD
Backup File Format H.264 file (AVI generator included)
Configuration Backup Via USB Device
Supported Operating Systems Windows™ XP, Vista, 7, 8
Mac OSX Snow Leopard 10.6 or above
Browser Internet Explorer & Safari 6.0
Email Notification Text with snapshot
Instant Smart Phone Compatibility* Smart Phone & Tablet Compatibility: iPad™,
iPhone™, Android (version 2.3 & above).
System Configuration Full setup configuration over network
Ports Programmable by user
Network Protocol TCP/IP, DHCP, UDP, DDNS, PPPoE
Network Interface 10/100-Base-TX, RJ-45
Network Speed Control 48kb~8MB/sec.
Firmware Upgrade Via USB device and network
Time Synchronization Auto time sync by NTP server
Storage & Backup
Network
Recording Speed D3304/D3308/D3316/D3332:
960H (960x480) @ 30fps per channel / D1 (720x480) @ 30fps
per channel
D3216:
480x240 @ 30fps per channel / CIF (360x240) @ 30fps per
channel / D1 (720x480) @ 14fps per channel / 2CIF (720x240)
@ 14fps per channel / 960H (960x480) @ 10fps per channel /
960x240 @ 10fps per channel
Recording Quality Control 3 levels
Motion Area Setting Adjustable grid (30x44) NTSC
Adjustable grid (36x44) PAL
Sensitivity Levels 8
Pre Recording Max 10 seconds
Post Recording Max 5 minutes
Covert Video Yes
