Appendix E: Replacing the Hard Drive

4 Connect the power and data connectors.

5 Slide the top HDD plate in at the angle shown and lower into place.

6 Replace the center beam screw.

Step 2B of 3: Install hard drives 1~4:

1 Place the HDD(s) under the top HDD plate upside down with the power and data connectors

acing the rear of the DVR. Insert 4x hard drive screws per HDD.

2 Connect the power and data connectors.
