031914 M2-17
Loaf Lift: The Loaf Lift screen allows you to
test the Loaf Lift operation. (Illustration 27)
Raise: Moves the Loaf Lift from the
“Load”position (down) to the “Sweep”
position (up).
Lower: Moves the Loaf Lift from the
“Sweep” position (up) to the “Load”
position (down).
EStop: Stops the Loaf Lift movement
when using one of the tests.
Loaf Trays: The Loaf Trays screen allows
you to test the operation of the Loaf Trays.
(Illustration 28)
1. Touch “Raise” to raise a Loaf Tray.
2. Touch “Lower” to lower a Loaf Tray.
ILLUSTRATION 27
RAISE
LOWER
ESTOP
ILLUSTRATION 28
LOAF
TRAYS
