24 VDC DYNAMIC SCALE CONVEYOR
STEPPER MOTORS:
The Stepper Drive Modules receive operating
instructions from the Computer through the
AR15 Scale Driver Control Node.
(Illustration 25) Depending on the machine
options, the PowerMax3000
TM
Slicer can have
up to 3 Dynamic Scale Conveyors. Each Scale
Conveyor has its own Stepper Drive Module.
The Stepper Modules control the Motor Power
Voltage that runs each of the Scale Conveyor
Motors.
ILLUSTRATION 25
AR15 SCALE DRIVER CONTROL NODE
