M3-24 031914
X122 Terminal Connector: The X122
Terminal Strip receives Status Input Signals
from various components on the Slicer.
(Illustration 37) The U2 Motion Controller
uses these inputs to determine which Servo
Motors are safe to operate.
Terminal 7: Future use.
Terminal 8: Future use.
Terminal 10: Future use.
Terminal 11: Future use.
X132 Terminal Connector: The X132
Terminal Strip receives a 24 VDC Status
Input Signals from various components on
the Slicer.
Terminal 1: Future use.
Terminal 2: Future use.
Terminal 3: Future use.
Terminal 5 and 6: Jumped.
X122
ILLUSTRATION 37
U2 MODULE
X124
X132
