GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5344303-100, REVISION 3 VIVID P3 SERVICE MANUAL
Chapter 8 Replacement Procedures 8-37
6) Remove the LH-side EMI cover and remove two screws from LH-side bottom of the top assembly of
the system. Refer Figure 8-31 on page 8-37
Figure 8-31 Removing screw top assembly
7) Remove RH-side EMI cover and remove two screws from RH-side bottom of the top assembly of the
system. Refer Figure 8-32 on page 8-37
Figure 8-32 Removing screw top assembly
