GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5344303-100, REVISION 3 VIVID P3 SERVICE MANUAL
Chapter 3 Installation 3-23
J.) Connect the Color printer HP Laser jet P2015/ HP Officejet Pro K550/K5400/460, HP Officejet 6000
to the system. The USB Cable & power cable can be properly connected to the USB Ports & Power
Port in the Rear panel. Configure the printer, Config>Connectivity>Service>Standard print and
select the respective printer.
K.) Connect the external monitor to the system. The monitor can be properly connected using the VGA
port in the Rear panel.
Press Ctrl+Alt+V
on the keyboard, a dialog box appears.
Select Intel(R) Dual Display Clone
; check the Same display configuration driver on both display box and
select OK
.
NOTE: Please refer to the operation manual for each peripheral information needed by the user to
operate the system safely.
Figure 3-17 Color Printer Connection on the rear panel
Figure 3-18 Graphics Controller Properties
Power Cable USB Cable USB Cable
Power cable
To Next Page
