7. NIBP: Press to start or stop NIBP measurement.
8. DISP: Click to shi the display modes or return to the Main Screen from other screens. Press it to shi
between Main Screen and Display 2 Screen which can be set in System Menu screen.
9. Navigaon Knob: It is the major operang key of the system, which can be used to select funcons or
parameters. Press and release it to shi the screen and to conrm the funcon or other operang ps.
10. Alarm indicator:
Indicator Color Alarm Level
Red ashing High priority alarm
Yellow ashing Middle priority alarm
Yellow light Low priority alarm
Green light Normal
Le and Right Panel
Figure 2.2 the le panel Figure 2.3 the right panel
Dierent ports are located in dierent posions of the monitor for operang convenience.
The cable and transducer ports are at the le panel, shown in Figure 2.2.
 SpO
2
: SpO
2
probe connector
 NIBP: NIBP hose connector
 TEMP: TEMP probe connector
