96
Figure 94 Modify a VLAN
3. Configure the description and port members for the VLAN as described in Table 46.
4. Click Apply.
Table 46 Configuration items
Item Descri
tion
ID
Display the ID of the VLAN to be modified.
Description
Set the description string of the VLAN.
By default, the description string of a VLAN is its VLAN ID, such as VLAN 0001.
Port
Untagged
Member.
Find the port to be modified and select the Untagged Member, Tagged Member, or
Not a Member option for the port:
• Untagged: Indicates that the port sends the traffic of the VLAN with the VLAN tag
removed.
• Tagged: Indicates that the port sends the traffic of the VLAN without removing the
VLAN tag.
• Not a Member: Removes the port from the VLAN.
IMPORTANT:
When you configure an access port as a tagged member of a VLAN, the link type of the
port is automatically changed into hybrid.
Tagged
Member.
Not a
Member.
Modifying a port
1. Select Network > VLAN from the navigation tree
2. Click the Port tab to enter the page as shown in Figure 95.
Figure 95 Port configura
tion page
