355
Item Descri
tion
Check Logging
Select this option to log matching IPv4 packets.
A log entry contains the ACL rule number, action on the matching packets, protocol
that IP carries, source/destination address, source/destination port number, and
number of matching packets.
Source IP Address
Select the Source IP Address option and enter a source IPv4 address and source
wildcard, in dotted decimal notation.
Source Wildcard
Time Range
Select the time range during which the rule takes effect.
Configuring a rule for an advanced IPv4 ACL
1. Select QoS > ACL IPv4 from the navigation tree.
2. Click the Advanced Setup tab to enter the rule configuration page for an advanced IPv4 ACL.
