H3C WA Series User Manual

61
Item Descri
p
tion
Interface Status
Display and set the interface status.
• The display of Connected indicates that the current status of the interface is up
and connected. You can click Disable to shut down the interface.
• The display of Not connected indicates that the current status of the interface is
up but not connected. You can click Disable to shut down the interface.
• The display of Administratively Down indicates that the interface is shut down
by the administrator. You can click Enable to bring up the interface.
After you click Enable or Disable, the page displaying interface information
appears.
IMPORTANT:
For an interface whose status cannot be changed, the Enable or Disable button is not
available.
Working Mode Set the interface to work in bridge mode or router mode.
Interface management configuration example
Network requirements
Create VLAN-interface 100 and specify its IP address as 10.1.1.2.
Configuration procedure
1. Create VLAN 100:
a. Select Network > VLAN from the navigation tree.
The VLAN tab page appears.
b. Click Add.
The page for creating VLANs appears.
Figure 54 Create VLAN 100
c. Enter VLAN ID 100.
d. Click Apply.
2. Create VLAN-interface 100 and assign an IP address for it:
a. Select Device > Interface from the navigation tree.
b. Click Add.
The page for creating an interface appears.
