360
Item Descri
p
tion
MAC
Address
Filter
Source MAC
Address
Select the Source MAC Address option and enter a source MAC address
and wildcard.
Source Mask
Destination MAC
Address
Select the Destination MAC Address option and enter a destination MAC
address and wildcard.
Destination Mask
COS(802.1p priority) Specify the 802.1p priority for the rule.
Type Filter
LSAP Type
Select the LSAP Type option and specify the
DSAP and SSAP fields in the LLC
encapsulation by configuring the following
items:
• LSAP Type—Indicates the frame
encapsulation format.
• LSAP Mask—Indicates the LSAP
wildcard.
IMPORTANT:
The LSAP Type option is
mutually exclusive with the
Protocol Type option.
LSAP Mask
Protocol Type
Select the Protocol Type option and specify
the link layer protocol type by configuring
the following items:
• Protocol Type—Indicates the frame type.
It corresponds to the type-code field of
Ethernet_II and Ethernet_SNAP frames.
• Protocol Mask—Indicates the wildcard.
Protocol Mask
Time Range
Select the time range during which the rule takes effect.
Adding an IPv6 ACL
1. Select QoS > ACL IPv6 from the navigation tree.
2. Click the Add tab to enter the IPv6 ACL adding page.
