359
Figure 390 Configuring a rule for an Ethernet frame header ACL
3. Configure an Ethernet frame header IPv4 ACL rule as described in Table 115.
4. Click Add.
Table 115 Configuration items
Item Descri
tion
ACL
Select the Ethernet frame header IPv4 ACL for which you want to configure
rules.
Available ACLs are Ethernet frame header IPv4 ACLs.
Rule ID
Select the Rule ID option and enter a number for the rule.
If you do not specify the rule number, the system assigns one automatically.
IMPORTANT:
If the rule number you specify already exists, the following operations modify
the configuration of the rule.
Action
Select the action to be performed for IPv4 packets matching the rule.
• Permit—Allows matching packets to pass.
• Deny—Drops matching packets.
