7
Figure 5 Wireless configuration page
2. Configure the parameters as described in Table 6.
Table 6 Configuration items
Item Descri
tion
Primary Service
Authentication type
Select the authentication type for the wireless service, which can be:
• None—Performs no authentication.
• User authentication (802.1X)—Performs 802.1X authentication.
The default authentication type is None. In that case, skip the 5/8: Radius
Configuration step.
Wireless Service Specify the Service Set Identifier (SSID).
Encrypt
Select this box to go to the 6/8: Encryption Configuration step.
By default, no encryption is performed. If this option is not selected, the 6/8:
Encryption Configuration step is skipped.
RADIUS configuration
1. On the wireless configuration page, select User authentication (802.1X) for the Primary Service
Authentication Type field.
2. Click Next.
3. The RADIUS configuration page appears.
