103
Item Descri
tion
Advanced
Options
VLAN ID.
Enter a VLAN ID and specify a port for the static ARP entry.
IMPORTANT:
The VLAN ID must be the ID of the VLAN that has already been created, and the port
must belong to the VLAN. The corresponding VLAN interface must have been created.
Port.
Removing ARP entries
1. Select Network > ARP Management from the navigation tree to enter the default ARP Table page
shown in Figure 101.
2. Remov
e ARP entries:
î™» To remove specific ARP entries, select target ARP entries, and click Del Selected.
î™» To remove all static and dynamic ARP entries, click Delete Static and Dynamic.
î™» To remove all static ARP entries, click Delete Static.
î™» To remove all dynamic ARP entries, click Delete Dynamic.
Configuring gratuitous ARP
1. Select Network > ARP Management from the navigation tree.
2. Click the Gratuitous ARP tab to enter the page shown in Figure 103.
Figure 103 Gratuitous AR
P configuration page
3. Configure gratuitous ARP as described in Table 49.
Table 49 Configuration items
Item Descri
tion
Disable gratuitous ARP packets
learning function
Disable learning of ARP entries according to gratuitous ARP packets.
This function is enabled by default.
Send gratuitous ARP packets when
receiving ARP requests from another
network segment
Enable the device to send gratuitous ARP packets upon receiving ARP
requests from another network segment.
This function is disabled by default.
