ENGINE

- 161 -

No. Part Name Qty Remarks

11 Shaft/pin 1/2

12 Oil pump housing 1

13 Oil pump gear 1

14 Water pump Ⅱ gear/circlip 1/1

15 Shaft/pin 1/1

16 Water pump Ⅰ gear/washer 1/1

17 Oil pump middle gear 1

18 Shaft 1

19 Bearing 1

20 Fuel and air separator assy 1

21 V-ring 1

22 Shaft 1

23 Valve piece plate 1
