Hisun HS800UTV - Page 176

To Next Page

To Previous Page

ENGINE

- 162 -

No. Part Name Qty Remarks

24 Valve piece 1

25 Chain plate 1

26 Timing chain guide(secondly cylinder) 1

27 Timing chain 1

28 Right crankcase 1

For assembly, reverse the disassembly

procedure.
