Hisun HS800UTV - Page 248

To Next Page

To Previous Page

CHASSIS

- 234-

No. Part Name Qty Remarks

10 Gasket 0.1, Terminal Pad 1

Gasket 0.2, Terminal Pad 1

11 Bearing 32010E 1

12 Bearing seat 1

13 Clutch claw 1

14 Fuel outlet gasket 1

15 Oil outlet bolt 1

16 Fork fabrication 1

17 Clip 1

18 Support bracket 1

19 Return spring 1

20 Fork bush 1
