CHASSIS
- 235-
No. Part Name Qty Remarks
21 Fork column pin 1
22 Differential bolt M10×1.25×20 8
23 Oil inlet bolt, rear bridge 1
24 O-Ring, rear bridge oil inlet hole 1
25 Column Pin Φ4×28 1
26 Bolt M10×1.25 2
27 Mechanical brake disc 1
28 Column pin 1
29 Planetary gear 2
30 Adjustment gasket 2
31 Drive & driven gears assembly 1
32 Gasket,rear bridge drive gears 1
To Next Page
