Hisun HS800UTV - Page 78

SPECIFICATIONS
- 64-
Item Standard Limit
Stem-to-guide clearance IN
EX
Stem runout limit
Valve seat width
IN
EX
0.010 ~ 0.037 mm
(0.0004 ~ 0.0015 in)
0.025 ~ 0.052 mm
(0.0010 ~ 0.0020 in)
----
0.9 ~ 1.1 mm
(0.0354 ~ 0.0433 in)
0.9 ~ 1.1 mm
(0.0354 ~ 0.0433 in)
0.08 mm
(0.0031 in)
0.10 mm
(0.0039 in)
0.01 mm
(0.0004 in)
----
----
Valve spring
Inner spring
Free length IN
EX
Set length (valve closed) IN
EX
Compressed pressure
(installed) IN
EX
Tilt limit
* IN
EX
Direction of winding
(top view)
IN
EX
41.0mm (1.61 in)
41.0mm(1.61in)
31.0mm (1.22 in)
31.0 mm(1.22 in)
250.0 ~ 290.0N
(25.51 ~ 29.59 kg, 56.25 ~ 65.25 lb)
250.0 ~ 290.0N
(25.51 ~ 29.59 kg, 56.25 ~ 65.25 lb)
----
----
Clockwise
Clockwise
----
----
----
----
----
----
----
----
2.5°/1.4 mm
(2.5°/0.055 in)
2.5°/1.6 mm
(2.5°/0.063 in)
----
----
