Bit 7—Compare-match Interrupt Enable B (CMIEB): This bit selects whether to request
compare-match interrupt B (CMIB) when compare-match flag B (CMFB) in the timer
status/control register (TCSR) is set to “1.”
Bit 7
CMIEB Description
0 Compare-match interrupt request B (CMIB) is disabled. (Initial value)
1 Compare-match interrupt request B (CMIB) is enabled.
Bit 6—Compare-match Interrupt Enable A (CMIEA): This bit selects whether to request
compare-match interrupt A (CMIA) when compare-match flag A (CMFA) in the timer
status/control register (TCSR) is set to “1.”
Bit 6
CMIEA Description
0 Compare-match interrupt request A (CMIA) is disabled. (Initial value)
1 Compare-match interrupt request A (CMIA) is enabled.
Bit 5—Timer Overflow Interrupt Enable (OVIE): This bit selects whether to request a timer
overflow interrupt (OVI) when the overflow flag (OVF) in the timer status/control register (TCSR)
is set to “1.”
Bit 5
OVIE Description
0 The timer overflow interrupt request (OVI) is disabled. (Initial value)
1 The timer overflow interrupt request (OVI) is enabled.
Bits 4 and 3—Counter Clear 1 and 0 (CCLR1 and CCLR0): These bits select how the timer
counter is cleared: by compare-match A or B or by an external reset input.
Bit 4 Bit 3
CCLR1 CCLR0 Description
0 0 Not cleared. (Initial value)
0 1 Cleared on compare-match A.
1 0 Cleared on compare-match B.
1 1 Cleared on rising edge of external reset input signal.
211
