17.2.2 Socket Adapter Pin Arrangements and Memory Map
The H8/532 can be programmed with a general-purpose PROM writer by attaching a socket
adapter as listed in table 17-3. The socket adapter depends on the type of package. Figure 17-2
shows the socket adapter pin arrangements by giving the correspondence between H8/532 pins
and HN27C256 pin functions. Figure 17-3 is a memory map.
Table 17-3 Socket Adapter
Package Socket Adapter
84-Pin PLCC (CP-84) HS538ESC01H
84-Pin windowed LCC (CG-84) HS538ESG01H
80-Pin plastic QFP (FP-80A) HS538ESH01H
297
