Hitachi H8/500 Series - Combinations of Page Registers with Other Registers

Code Page Register (CP): The code page register and the program counter combine to generate
a 24-bit program code address. In the maximum mode, the code page register is initialized at a
reset to a value loaded from the vector table, and both the code page register and program counter
CP
DP
EP
TP
PC
R0
R4
R5
R6
R7
R1
R2
R3
@ aa : 16
Page register
8 Bits 16 Bits
24 Bits (effective address)
PC or general register
Figure 3-4 Combinations of Page Registers with Other Registers
