14.2.7 Serial Status Register (SSR)—H'FFDC
* Software can write a 0 to clear the flags, but cannot write a 1 in these bits.
The SSR is an 8-bit register that indicates transmit and receive status. It is initialized to H'87 at a
reset and in the standby modes.
Bit 7—Transmit Data Register Empty (TDRE): This bit indicates when the TDR contents have
been transferred to the TSR and the next character can safely be written in the TDR.
Bit 7
TDRE Description
0 This bit is cleared from 1 to 0 when:
1. The CPU reads the TDRE bit, then writes a 0 in this bit.
2. The data transfer controller (DTC) writes data in the TDR.
1 This bit is set to 1 at the following times: (Initial value)
1. The chip is reset or enters a standby mode.
2. When TDR contents are transferred to the TSR.
3. When TDRE = 0 and the TE bit is cleared to 0.
Bit 6—Receive Data Register Full (RDRF): This bit indicates when one character has been
received and transferred to the RDR.
Bit 6
RDRF Description
0 This bit is cleared from 1 to 0 when: (Initial value)
1. The CPU reads the RDRF bit, then writes a 0 in this bit.
2. The data transfer controller (DTC) reads the RDR.
3. The chip is reset or enters a standby mode.
1 This bit is set to 1 when one character is received without error and transferred from the
RSR to the RDR.
Bit 76543210
TDRE RDRF ORER FER PER — — —
Initial value 10000111
Read/Write R/(W)* R/(W)* R/(W)* R/(W)* R/(W)* ———
253
