Bit 4—Receive Enable (RE): This bit enables or disables the receive function. When the receive
function is enabled, the RXD pin is automatically used for input. When the receive function is
disabled, the RXD pin is available as a general-purpose I/O port.
Bit 4
RE Description
0 The receive function is disabled. The RXD pin can be (Initial value)
used as a general-purpose I/O port.
1 The receive function is enabled. The RXD pin is used for input.
Bits 3 and 2—Reserved: These bits cannot be modified and are always read as 1.
Bit 1—Clock Enable 1 (CKE1): This bit selects the internal or external clock source for the
baud rate generator. When the external clock source is selected, the SCK pin is automatically
used for input of the external clock signal.
Bit 1
CKE1 Description
0 Internal clock source. (Initial value)
1 External clock source. (The SCK pin is used for input.)
Bit 0—Clock Enable 0 (CKE0): When an internal clock source is used in synchronous mode,
this bit enables or disables serial clock output at the SCK pin.
This bit is ignored when the external clock is selected, or when the asynchronous mode is
selected.
For further information on the communication format and clock source selection, see tables 14-5
and 14-6 in section 14.3, “Operation.”
Bit 0
CKE0 Description
0 The SCK pin is not used by the SCI (and is available as (Initial value)
a general-purpose I/O port).
1 The SCK pin is used for serial clock output.
252
