9.7.4 Built-in MOS Pull-Up
Port 6 has programmable MOS input pull-ups which are turned on by clearing the corresponding
bit in P6DDR to “0” and writing a “1” in P6DR. These pull-ups are turned off at a reset and in the
hardware standby mode. Table 9-11 indicates the status of the MOS pull-ups in various modes.
Table 9-11 Status of MOS Pull-Ups for Port 5
Mode Reset Hardware Standby Mode Other Operating States*
1 OFF OFF
2
3 OFF
4
7
* Including the software standby mode.
Notation:
OFF: The MOS pull-up is always off.
ON/OFF: The MOS pull-up is on when P6DDR = 0 and P6DR = 1, and off otherwise.
Note: When using the built-in pull-ups, see the “Note on Usage of MOS Pull-Ups” in
section 9.6.4.
9.8 Port 7
9.8.1 Overview
Port 7 is an 8-bit input/output port with the pin configuration shown in figure 9-19. Its pins also
carry input and output signals for the on-chip free-running timers (FRT1, FRT2, and FRT3), and
two input signals for the on-chip 8-bit timer.
P63 (input/output)
Port P6
2 (input/output)
6P6
1 (input/output)
P6
0 (input/output)
ON/OFF
ON/OFF
Figure 9-18 Port 6 Pin Functions in Modes 7, 2, and 1
167
