Bit 4—Parity Mode (O/E): In asynchronous mode, when parity is enabled (PE = 1), this bit
selects even or odd parity.
Even parity means that a parity bit is added to the data bits for each character to make the total
number of 1’s even. Odd parity means that the total number of 1’s is made odd.
This bit is ignored when PE = 0 and in the synchronous mode.
Bit 4
O/E Description
0 Even parity. (Initial value)
1 Odd parity.
Bit 3—Stop Bit Length (STOP): This bit selects the number of stop bits. It is ignored in the
synchronous mode.
Bit 3
STOP Description
0 1 Stop bit. (Initial value)
1 2 Stop bits.
Bit 2—Reserved: This bit cannot be modified and is always read as 1.
Bits 1 and 0—Clock Select 1 and 0 (CKS1 and CKS0): These bits select the internal clock
source when the baud rate generator is clocked from within the H8/532 chip.
Bit 1 Bit 0
CKS1 CKS0 Description
0 0 ø clock (Initial value)
0 1 ø/4 clock
1 0 ø/16 clock
1 1 ø/64 clock
250
