Bit 5—A/D Start (ADST): The A/D converter operates while this bit is set to 1. In the single
mode, this bit is automatically cleared to 0 at the end of each A/D conversion.
Bit 5
ADST Description
0 A/D conversion is halted. (Initial value)
1 1. Single mode: One A/D conversion is performed. The ADST bit is automatically
cleared to 0 at the end of the conversion.
2. Scan mode: A/D conversion starts and continues cyclically on the selected channels
until the ADST bit is cleared to 0.
Bit 4—Scan Mode (SCAN): This bit selects the scan mode or single mode of operation.
See section 15.4, “Operation” for descriptions of these modes.
The mode should be changed only when the ADST bit is cleared to 0.
Bit 4
SCAN Description
0 Single mode (Initial value)
1 Scan mode
Bit 3—Clock Select (CKS): This bit controls the A/D conversion time.
The conversion time should be changed only when the ADST bit is cleared to 0.
Bit 3
CKS Description
0 Conversion time = 274 states (Initial value)
1 Conversion time = 138 states
Bits 2 to 0—Channel Select 2 to 0 (CH2 to CH0): These bits and the SCAN bit combine to
select one or more analog input channels.
The channel selection should be changed only when the ADST bit is cleared to 0.
